Global - Land High Latitude Temperate Latitudes

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Overall Score [1]
Benchmark	[-]	120.
ACCESS-ESM1-5	[-]	148.		28.3	52.3	0.408		0.700	0.618	0.973	0.727
BCC-CSM2-MR	[-]	139.		19.5	53.7	0.407		0.802	0.610	0.973	0.749
BGCLND	[-]	133.		11.8	41.5	0.272		0.818	0.668	0.982	0.784
BGCLNDATM_progCO2	[-]	135.		14.6	43.7	0.272		0.844	0.624	0.982	0.769
CanESM5	[-]	140.		17.5	42.4	0.474		0.808	0.652	0.969	0.770
CNRM-ESM2-1	[-]	144.		23.7	57.9	0.542		0.764	0.633	0.964	0.749
EC-Earth3-CC	[-]	140.		17.2	47.7	0.543		0.838	0.650	0.964	0.776
MeanCMIP6	[-]	139.		18.8	43.5	0.136		0.823	0.679	0.991	0.793
MIROC-ES2L	[-]	144.		23.1	56.2	0.476		0.796	0.641	0.968	0.762
MPI-ESM1-2-LR	[-]	139.		21.8	52.7	0.340		0.778	0.648	0.977	0.763
MRI-ESM2-0	[-]	134.		11.6	45.2	0.474		0.836	0.646	0.969	0.774
NorESM2-LM	[-]	140.		22.8	46.9	0.271		0.724	0.649	0.982	0.751
UKESM1-0-LL	[-]	138.		17.3	45.5	0.339		0.797	0.651	0.978	0.769

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Overall Score [1]
Benchmark	[-]	61.4
ACCESS-ESM1-5	[-]	93.3		13.0	51.7	0.683		0.762	0.483	0.915	0.660
BCC-CSM2-MR	[-]	76.9		-7.35	26.8	1.02		0.778	0.559	0.893	0.697
BGCLND	[-]	75.2		5.14	50.9	0.344		0.826	0.578	0.977	0.740
BGCLNDATM_progCO2	[-]	70.0		-7.60	28.9	0.683		0.844	0.536	0.915	0.708
CanESM5	[-]	82.0		-1.60	28.9	1.02		0.824	0.606	0.893	0.732
CNRM-ESM2-1	[-]	97.4		14.1	50.9	0.344		0.745	0.545	0.977	0.703
EC-Earth3-CC	[-]	85.4		-2.41	19.9	1.02		0.830	0.647	0.893	0.754
MeanCMIP6	[-]	80.6		1.05	29.2	0.683		0.834	0.637	0.915	0.756
MIROC-ES2L	[-]	93.6		12.8	47.3	1.02		0.835	0.604	0.893	0.734
MPI-ESM1-2-LR	[-]	77.6		-9.00	25.6	1.02		0.843	0.590	0.893	0.729
MRI-ESM2-0	[-]	82.8		-1.89	30.0	0.344		0.872	0.618	0.977	0.771
NorESM2-LM	[-]	79.1		-6.89	26.1	0.683		0.748	0.617	0.915	0.724
UKESM1-0-LL	[-]	80.6		-2.52	32.0	0.683		0.796	0.614	0.954	0.745

	Download Data	Period Mean (original grids) [Watt m-2]		Bias [Watt m-2]	RMSE [Watt m-2]	Phase Shift [months]		Bias Score [1]	RMSE Score [1]	Seasonal Cycle Score [1]	Overall Score [1]
Benchmark	[-]	128.
ACCESS-ESM1-5	[-]	148.		30.3	45.1	0.407		0.687	0.671	0.973	0.750
BCC-CSM2-MR	[-]	134.		14.3	38.0	0.407		0.838	0.643	0.973	0.774
BGCLND	[-]	132.		7.64	31.2	0.305		0.840	0.716	0.980	0.813
BGCLNDATM_progCO2	[-]	132.		9.82	34.1	0.203		0.867	0.667	0.987	0.797
CanESM5	[-]	137.		13.5	34.8	0.610		0.838	0.689	0.960	0.794
CNRM-ESM2-1	[-]	143.		15.2	37.3	0.712		0.783	0.680	0.953	0.774
EC-Earth3-CC	[-]	136.		9.94	34.3	0.508		0.853	0.674	0.966	0.792
MeanCMIP6	[-]	133.		13.6	31.8	0.203		0.830	0.716	0.987	0.812
MIROC-ES2L	[-]	139.		17.5	37.2	0.610		0.781	0.675	0.960	0.773
MPI-ESM1-2-LR	[-]	136.		15.2	34.9	0.102		0.811	0.685	0.993	0.794
MRI-ESM2-0	[-]	131.		8.39	34.8	0.508		0.825	0.680	0.966	0.788
NorESM2-LM	[-]	141.		22.8	38.3	0.407		0.743	0.683	0.973	0.771
UKESM1-0-LL	[-]	132.		9.60	33.2	0.305		0.837	0.686	0.980	0.797

Equatorial Africa Equatorial Asia Global - Land High Latitude South America - Amazon Temperate Latitudes Temporally integrated period mean Temporally integrated period mean bias Temporally integrated period mean bias score Temporally integrated period mean max month Temporally integrated mean phase shift Temporally integrated mean phase shift score Temporally integrated period mean rmse Temporally integrated period mean rmse score Spatially integrated regional mean cycle Spatially integrated regional mean detrended cycle Spatially integrated regional mean

  Title:

derived WRMC BSRN

  Source_file:

This product is generated from monthly WRMC.BSRN observations

  Conventions:

Please contact Prof. James Randerson (Email: jranders@uci.edu) or Dr. Mingquan Mu (mmu@uci.edu) for any question

  Altitude:

BSRN

  Site_name:

ASP,BAR,BER,BIL,BON,BOS,BOU,BRB,CAB,CAM,CAR,CLH,CNR,COC,DAA,DAR,DOM,DRA,DWN,E13,EUR,FLO,FPE,FUA,GCR,GVN,ILO,ISH,IZA,KWA,LAU,LER,LIN,MAN,MNM,NAU,NYA,PAL,PAY,PSU,PTR,REG,RLM,SAP,SBO,SMS,SOV,SPO,SXF,SYO,TAM,TAT,TIK,TOR,XIA

  Creation_date:

Mon Jun 23 15:56:09 PDT 2014

  Approach:

First I used BSRN Toolbox to extract swdn (surface downward shortwave radiation) and swup (surface upward shortwave radiation) from raw data files, and saved the data in ascii format, then I calculated surface net shortwave radation using swdn and swup, and organized all site data together for each month and year and saved them in netcdf files.

  Temporal resolution:

monthly

  General information:

This product was derived from WRMC-BSRN radiation dataset.

  Spatial resolution:

site observations

  Derived data code:

http://redwood.ess.uci.edu/mingquan/www/ILAMB/Download/CODES/CODES/subroutines/convert/convert-WRMC.BSRN.ncl
